P/L-3
EBZ8050/RH
Fig.1 BLOWER GROUP EBZ8050/EBZ8050RH (S/N 90100101 and up)
Key# Part Number Description Q'ty
1 848-L58-55A4 VOLUTE CASE 1
4 848-L58-55Z0 VOLUTE COVER 1
5 848-L58-55G0 BRACKET 2
6 2750-72230 CLAMP (RH Only) 1
7 T4970-52510 SCREW TORX 17
8 T4970-51410 SCREW TORX 4
9 848-L58-55C2 ELBOW 1
10 07000-12100 O-RING 1
11 T4960-57030 SCREW TORX 2
12 3310-53331 NUT 2
13 848-L58-55D4 COVER INLET 1
14 848-8K4-0010 CLAMP 1
15 848-L58-55J0 CAP 1
16 848-L59-52A0 FAN 1
17 848-816-3500 BOLT TORX 4
18 848-L58-31A3 ENGINE COVER 1
19 T4970-52510 SCREW TORX 4
20 848-L5M-3502 FRAME ASSY 1
21 848-L5M-35A0 • FRAME 1
23 848-L58-3613 • BAND ASSY 2
24 848-L58-36C1 • CLIP 2
25 848-L58-35C2 PAD 1
26 3495-21320 CLIP 6
27 848-L58-3521 NET COMP. 1
28 1480-74710 CLIP 4
29 2750-32510 DAMPER 1
30 848-870-5040 WASHER 1
31 848-815-4000 BOLT TORX 1
32 T4960-51631 SCREW TORX 2
33 2750-32610 DAMPER 2
34 2750-32620 NUT (M6) 2
35 848-L58-83A2 BODY, CLEANER 1
36 848-L58-83U2 CASE, INNER 1
37 848-L58-8322 COVER ASSY 1
38 – • COVER 1
39 T4012-82220 • COVER 1
40 T4970-52510 • SCREW TORX 2
41 848-L58-83J1 • KNOB BOLT 2
42 T4012-82311 ELEMENT 1
43 T4012-82321 ELEMENT 1
44 848-L58-83P2 HOSE 1
45 848-8K4-0001 CLAMP 2
46 T4950-52030 BOLT TORX 4
47 848-864-5000 NUT 4
48 848-L60-8511 TANK ASSY 1
49 848-L23-8510 • CAP ASSY 1
50 4500-85300 • • HOLDER ASSY 1
Key# Part Number Description Q'ty
51 4500-85220 • • PACKING 1
52 5601-85260 • • FILTER 1
53 848-L23-85N0 • • STOPPER 1
54 848-L58-8530 • PIPE COMP. 1
55 3302-85400 • FILTER 1
56 1260-85460 • CLIP 1
57 T4960-51231 SCREW TORX 3
58 1950-86120 CLIP 1
60 848-8X1-0070 LABEL, CAUTION 1
62 848-L6K-90R0 LABEL 1
63 848-L6K-90S0 LABEL 1
64 T4012-82280 LABEL 1
65 848-8X5-0770 LABEL, SOUND 1
70 848-L65-65A0 HOSE 1
71 848-L58-6510 SWIVEL JOINT 1
72 848-L58-65D0 PIPE, STRAIGHT 1
73 848-L58-65E1 PIPE, END 1
74 848-8K4-0021 CLAMP 1
75 848-8K4-0031 CLAMP 1
76 848-L58-3621 BAND ASSY Acc
80 848-8U0-0020 TOOL-SET 1
81 3540-91120 • SPANNER 1
82 848-8U1-0020 • SOCKET 1
83 848-L58-35S0 NET 1
84 848-8K3-0030 CLIP 1
13. Parts list
