G3100T
55
1 T2050-12110 CYLINDER 1
2 T2050-21110 CRANKCASE 1
3 01252-30530 BOLT 4
4 2870-41111 PISTON 1
5 3319-41210 RING 1
6 3304-41310 PIN 1
7 3310-41320 SNAP RING 2
8 3310-41410 BEARING 1
9 1650-41510 WASHER 2
10 2870-42002 CRANKSHAFT COMP 1
11 06030-06201 BEARING 2
12 2630-43150 OIL SEAL 1
13 04065-03212 SNAP RING 1
14 2169-21210 OIL SEAL 1
15 2633-15100 MUFFLER ASS’Y 1
16 2633-15110 • BASE 1
17 2633-15120 • COVER 1
18 2630-15130 • BUFFLE 1
19 2633-15150 • SPARK ARRESTER 1
20 2630-15211 GASKET 1
21 3330-15220 BOLT 2
22 2633-15161 COVER 1
23 2870-22102 VALVE ASSY 1
24 2870-22211 GASKET 1
25 3330-14121 GASKET 1
26 2873-31100 ENGINE CASE COMP 1
27 2870-31510 VALVE 1
28 T2052-31200 FUEL PIPE ASSY 1
29 1492-85410 • PIPE 1
30 1850-85300 • FILTER ASSY 1
31 1260-85460 • CLIP 2
32 3350-34320 • ELBOW 1
33 T2052-31250 • GROMMET 1
34 3317-86100 BREATHER ASSY 1
35 2873-31300 OIL PIPE ASSY 1
36 2630-31321 • GROMMET 1
37 2873-31330 • JOINT 1
38 2630-31350 • FILTER 1
39 1492-85410 • PIPE 1
40 1492-85410 PIPE 1
41 3370-31210 PIN 1
42 2630-31510 VALVE ASSY 1
43 2870-22251 SEAL 1
44 2630-31650 CAP 1
45 2870-31750 SCREW M5x16 4
46 2841-31800 CAP ASSY 2
47 2630-31820 • GASKET 2
48 2630-31913 COVER FRONT 1
49 2630-31950 SCREW 2
50 2873-32100 FRONT HANDLE ASSY 1
51 2630-32121 • JOINT(A) 1
52 2630-32151 • STOPPER 1
53 2630-32170 • SCREW 1
54 2630-32170 SCREW 1
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
55 2630-32610 SCREW 2
56 T2050-33100 REAR HANDLE COMP 1
57 3330-33250 • STOPPER 1
58 3310-33262 • SPRING 1
59 3310-33271 • KNOB 1
60 2873-33312 THROTTLE LEVER 1
61 3356-33321 SPRING 1
62 04025-00524 PIN 1
63 848-C30-33E3 ARM 1
64 T2050-33410 COVER GRIP 1
65 2630-31950 SCREW 1
66 2630-33511 JOINT(B)(HARD) 1
67 2873-33520 JOINT(C)(SOFT) 2
68 2640-33530 BOLT 3
69 2630-33610 SCREW 6
70 2873-43230 NUT 1
71 2873-43240 WASHER 1
72 2873-43250 WASHER 1
73 2872-51111 CLUTCH DRUM 1
74 2873-51310 BEARING 1
75 2870-51200 CLUTCH ASSY 1
76 2873-98610 • PLATE 1
77 2870-51230 • SPRING 1
78 T2054-54000 CHAINBRAKE ASSY 1
79 T2050-54110 • GUARD 1
80 2872-54120 • SPRING 1
81 0263-80530 • SCREW 1
82 2872-54140 • SPACER 1
83 2850-54211 • SPACER 1
84 848-C20-5421 • WEIGHT 1
85 2872-54230 • SPRING 1
86 2851-54270 • SPRING 1
87 01641-20510 • WASHER 1
88 3310-53331 • NUT(B) 1
89 2851-54301 • LEVER COMP 1
90 2851-54350 • PIN 1
91 2670-54411 • ARM 1
92 2872-54510 • BAND 1
93 3356-24140 • PIN 1
94 2670-54610 • SPRING BRAKE 1
95 2872-54623 • COVER SPRING 1
96 2630-33610 • SCREW 3
97 T2054-53120 LABEL 1
98 3350-53410 NUT 1
99 2870-53310 PLATE(A) 1
100 2630-53330 SCREW 1
101 2873-53320 NUT(A) 1
102 2630-53412 CATCHER 1
103 2630-32170 SCREW 1
104 2630-55102 OIL PUMP ASSY 1
105 2630-55160 • GEAR WORM 1
106 0261-00416 SCREW 2
107 2630-55211 PLATE WORM 1
108 2630-55251 SEAL 1
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
109 2630-55312 COVER PUMP 1
110 2630-31950 SCREW 2
111 2873-71100 ROTOR ASSY 1
112 2873-71120 • PAWL 2
113 2873-71130 • SPRING 2
114 2873-71140 • PIN 2
115 2634-71110 MODULE 1
116 5500-72110 CAP 1
117 1900-72120 SPRING 1
118 T1512-71320 TUBE 1
119 2634-06711 SWITCH SET 1
120 2634-71120 • CORD EARTH 1
121 2630-72610 • WIRE SWITCH 1
122 5500-72150 SPACER 2
123 3310-72150 BOLT 2
124 1216-73110 SPARK PLUG 1
125 T2050-75000 STARTER ASSY 1
126 T2050-75100 • CASE COMP 1
127 3330-75121 • • GUIDE 1
128 2873-75210 • REEL 1
129 2873-75150 • ROPE 1
130 T2050-75420 • KNOB 1
131 2873-75220 • SPRING 1
132 2873-75410 • WASHER 1
133 2873-75510 • SCREW 1
134 2873-75610 • COVER FAN 1
135 2630-33610 • SCREW 1
136 2630-31950 SCREW 4
137 T2054-75130 LABEL 1
138 T2054-81000 CARBURETOR ASSY 1
139 3310-82110 WASHER 1
140 2875-82120 CHOKE PLATE 1
141 2630-82140 SCREW 2
142 2873-82151 THROTTLE ROD 1
143 2630-82160 GROMMET 1
144 2630-82210 GROMMET(A) 1
145 2875-82221 GROMMET(B) 1
146 2630-82311 CHOKE ROD 1
147 3320-33310 GROMMET 1
148 2630-98500 COVER ASSY 1
149 2630-83120 • KNOB 1
150 0308-00040 • SNAP RING 1
151 2630-83511 CLEANER 1
152 2870-83610 ELEMENT 1
153 T2054-31410 LABEL 1
154 T2052-31260 PIPE 1
155 2841-37150 JOINT 1
156 2850-81900 PUMP 1
157 T2052-31260 PIPE 1
158 T2054-31430 LABEL 1
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
To Next Page
