G3100T
Fig.2 CARBBURETOR COMPONENTS & ACCESSORIES (S/N 0723010001 and up)
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
1 T2054-81000 CARBURETOR ASS'Y
2 T2052-81120 • PUMP COVER 1
3 3310-81130 • SCREW 1
4 3310-81280 • COVER 1
5 1480-81420 • PLUG 1
6 3350-81380 • SPRING 1
7 2630-81330 • SCREW 1
8 2880-81470 • SCREW 2
9 3310-81341 • VALVE 1
10 2670-81410 • SPRING 1
11 2875-81370 • SHAFT ASS'Y 1
12 2630-81440 • LEVER 1
13 1148-81390 • RING 1
14 3310-81351 • SCREW 4
15 T2050-06020 • GASKET KIT 1
—• • PUMP, gasket 1
—• • PUMP, diaphragm 1
—• • GASKET 1
—• • DIAPHRAGM 1
16 3306-81380 • SCREEN 1
17 3356-81310 • VALVE, inlet 1
18 2841-81270 • SPRING 1
19 3310-81250 • PIN 1
20 3310-81230 • LEVER 1
21 3310-81240 • SCREW 1
31 G0011 BAR 14” (350mm) 1
32 91SG-52X CHAIN 91SG-52E 1
33 3617-97110 PROTECTOR 1 OP
34 3320-91140 WRENCH 1
35 3320-96410 STOPPER 1 OP
36 3330-97310 GUAGE 1 OP
37 2670-96210 WRENCH 1 OP
38 2670-96240 WRENCH 1 OP
39 2670-96410
WRENCH TORX (T20xT25xT25)
1OP
40 3304-97611
WRENCH TORX (B3xB4xB5)
1OP
To Next Page
