G621AVS
27
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
Fig.A-2 POWER UNIT (2)
1 3356-24101 Brake band comp. 1
2 3356-24111 • Band 1
3 3356-24120 • Arm 1
4 04025-00408 • Pin 1
5 3356-24140 Roller 1
6 2622-24210 Lever 1
7 848-C92-5431 Stopper 1
8 2622-24600 Spring 1
9 3356-24240 Spring 1
10 0308-00060 Snap ring 2
11 2623-25310 Spike 1
12 2616-25320 Screw 2
13 3356-26100 Cap assy 1
14 3317-57220 • Gasket 1
15 848-C90-3114 Cover comp. 1
16 3356-31120 • Cap 1
17 3356-31152 • Grommet 1
18 3356-31212 Seal 1
19 0263-90514 Screw 2
20 0263-90520 Screw 1
21 2620-32100 Left handle comp. 1
22 2851-32180 Plate 2
23 848-825-1901 Screw 4
24 2622-33005 Right handle assy 1
25 2622-33105 • Right handle comp. 1
26 3350-33220 • Plate 1
27 3330-33250 • Stopper 1
28 3310-33262 • Spring 1
29 3310-33271 • Knob 1
30 2810-33280 • Damper (A) 1
31 848-C10-33C3 • Lever 1
32 3356-33321 • Spring 1
33 04025-00524 • Pin 1
34 2616-33412 • Damper (B) 1
35 3356-34111 Cover 1
36 848-C30-33E3 Arm 1
37 3356-32210 Screw 1
38 3350-34400 Cap assy 1
39 3350-26110 • Cap 1
40 3317-57230 • Chain 1
41 3317-57240 • Stopper 1
42 0277-10410 • Screw 1
43 3350-34450 • Gasket 1
44 3350-51110 Drum 1
45 3360-51120 Sprocket 1 3/8Px7T
46 3356-53003 Chain cover assy 1
47 3356-53220 • Plate 1 K8
48 0277-10410 • Screw
49 3350-53410 Nut 2
50 3356-53210 Plate 1
51 0261-00410 Screw 1
53 2616-71112 Rotor 1
54 848-C90-71B1 Source coil 1
55 2616-71301 Ignition coil comp. 1
56 2616-71320 • Cap 1
57 2616-71331 • Cord 1
58 2616-71410 Cord 1
59 2616-71420 Cord 1
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
60 2616-71430 Cord 1
61 2618-71102 Rotor comp. 1
62 3366-71120 • Ratchet 2
63 3350-71131 • Spring 2
64 3388-71150 • Washer 2
65 3310-71142 • Boft 2
66 2850-72110 Cap 1
67 1400-72121 Spring 1
68 2850-71320 Tube 1
69 3350-15250 Bolt 2
70 0263-30416 Screw 2
71 3699-90002-10 Spark plug 1 CJ-7Y
72 3369-81000 Carburetor 1 See Fig.B
73 848-C91-8311 Air cleaner comp. 1 Net type
74 848-C90-83C0 • Plate 1
75 3369-83200 Silencer 1
76 2622-83302 Cover comp. 1
77 3356-83322 • Knob 1
78 3388-83340 • Gasket 1
79 3369-31163 Label 1
81 3359-53121 Label 1
82 3369-75131 Label 1
101 2610-83220 Cap 1 OP
102 2623-06012 Double spike kit 1 OP
103 2618-53002 • Chain cover assy 1 OP
104 3356-53220 • • Plate 1
105 0261-00410 • • Screw 1 K8
106 2616-53300 • • Protector 1 OP, K8
107 2618-53510 • Spike 1 OP, K8
108 3310-53331 • Nut 2 OP, K8
109 2670-14320 • Screw 2 OP, K8
110 2626-31110 Cover 1 OP
To Next Page
