Kickback and guide bar nose radius
For sprocket nose bars the nose radius is defined by the
number of teeth (for example 10T). For solid guide bars
the nose radius is defined by the size of the nose radius.
For a given guide bar length, you may use a guide bar
with smaller nose radius than listed.
Guide bar Saw chain
Length, in/mm Pitch, in Gauge, in/mm Max. nose ra-
dius
Type Length, drive
links (no.)
Low Kickback
14/36 3/8 0.050/1.3 7T RedMax H37 52 Yes
16/41 56
Filing equipment and filing angles
Use a RedMax file gauge to sharpen the saw chain. A
RedMax makes sure that you get the correct filing
angles. The part numbers are given in the table below.
If you are not sure how to identify the type of saw chain
on your product, refer to www.redmax.com for more
information.
H37 5/32 in / 4 mm 579 65 36-01
0.025 in / 0.65
mm
30° 80°
30 995 - 003 - 30.01.2019
