Reebok GX40s ELLIPTICAL - Parts Identification and Inventory; Component Breakdown

REEBOKFITNESSEQUIPMENT.COM
GX40s
CROSSTRAINER ASSEMBLY GUIDE
1/1
1/1
1/1
1/1
1/1
1/1
1/1
2/2/2
1/1/1
E580
allen bolt M8*16L(4)
O-1
O-5
Scre w M8*16L( 8)
O-7 Spring Washer
8.1*12.9*2.4t(2)
Flat washer 8.5* 25* 2T( 4)O-9
O-8:Hex bolt M8*20L(2)
Flat washer 10.2* 30* 1T( 2)
O-10
Flat washer 8*16*1T( 4)
O-6
O-3:
Carriage Bolt
M8*P1.25*40MM (4)
O-4: Curved Washer 8* 9*2T (6)
O-2: lock nut f or M8 (4)
O-13
Spring Washer 6(4)
Flat washer
6*13*1T( 4)
O-14
E580说明书
1/1
E580
Knob (foot pedal)M6*P1.0 (4)O-11
Carrage bolt M6*P1.0*50L (black)(4)O-12
Box Spanner (2)
Allen Key(2)
Allen Key(1)
Flat washer 12*19*1T( 4)O-15
