www.reebokfitness.com 11.
No. PART DESCRIPTION QTY No. PART DESCRIPTION QTY No. PART DESCRIPTION QTY
A01 base frame 1 C23 air cushion 4 D26 console panel sticker 1
A02 main frame 1 C24 safety key base 1 D27 function button sticker 1
A03 incline bracket 1 C25 volume control button 1 D28 filter 1
A04 console bracket 1 C26 base of volume control button 1 D29 inductance 1
A05 pulse bracket 2 C27 fan 1 D30 speed sensor 1
A06 left upright tube 1 C28 fan guide 1 E01 nut 2
A07 right upright tube 1 C29 fan axis 1 E02 nut 12
A08 motor bracket 1 C32 running belt 1 E03 nut 6
B01 front roller 1 C33 motor bottom cover 1 E04 bolt 1
B02 back roller 1 C34 black cushion 4 E05 bolt 1
B03 cylinder 1 C35 blue cushion 2 E06 bolt 4
B04 spanner and screw driver 1 C36 blue cushion 2 E07 bolt 4
B05 5mm allen key 1 C37 plastic pad 4 E08 bolt 2
B06 bushing 4 C38 motor belt 1 E09 bolt 5
B08 speaker net 1 C39 transport wheel 2 E10 bolt 2
B09 pulse steel plate 4 C40 adjustable wheel 2 E11 bolt 1
B10 spring plate 2 C41 ring-shape wire plug 2 E12 bolt 4
B11 side rail tighten sheet 6 C42 flat foot pad 4 E13 bolt 8
B12 locking pin 1 C43 cone-shape cushion 1 E14 bolt 1
B13 belt hook 2 C44 anti-slip pad 2 E15 bolt 1
B14 hide board 2 C45 sticker of anti-slip pad 2 E16 bolt 3
C01 console base 1 D01 computer board 1 E17 bolt 2
C02 console bottom cover 1 D02 control board 1 E18 bolt 6
C03 console back cover 1 D03 top signal wire 1 E19 bolt 4
C04 console panel 1 D04 middle signal wire 1 E20 bolt 11
C05 console panel bottom cover 1 D05 bottom signal wire 1 E21 bolt 21
C06 left water bottle holder 1 D06 pulse button 2 E22 screw 8
C07 right water bottle holder 1 D07 safety key 1 E23 screw 4
C08 pulse top cover 2 D08 ac single wire (blue) 1 E25 screw 2
C09 pulse bottom cover 2 D09 ac single wire (brown) 2 E26 screw 54
C10 handle bar 2 D10 ac single wire (brown 350mm) 1 E27 screw 23
C11 decoration strip i 1 D11 ac single wire (blue 350mm) 1 E28 screw 35
C12 decoration strip ii 1 D12 grounding wire 1 E29 screw 8
C13 handle bar decoration ring 2 D13 power wire 1 E30 screw 7
C14 motor top cover 1 D14 power socket 1 E31 washer 3
C15 left upright tube cover 1 D15 on-off button 1 E32 washer 14
C16 right upright tube cover 1 D16 overload protector 1 E33 washer 2
C14 motor top cover 1 D17 magnet ring 1 E34 spring washer 6
C15 left upright tube cover 1 D18 magnet core 1 E35 flat washer 11
C16 right upright tube cover 1 D19 incline motor 1 E36 big washer 8
C17 back end cover 1 D20 dc motor 1 E37 bolt 6
C18 left side rail 1 D21 running board 1 E38 screw 4
C19 right side rail 1 D22 speaker 2
C20 plastic holder 1 D23 audio board 1
C21 button board 1 D24 usb board 1
C22 cushion 2 D25 volume control board 1
