Ⅰ
﹕
Window and key-press instruction
A:“program Button: When the machine is in power on status this can be used to select a program: The programs
available are:manual modeP0->P01->P02->P03->P04->P05->P06->P07->P08->P09->P10->P11->P12
-> test body fat 。
B: mode Button :
1．When the machine is running,press the “mode” key to cycle between distance, time, calories or scan mode. If
scan is selected each segment will be displayed for a period of 6 seconds；2．When in the power on screen it is a
setting mode key :
3. When in the p0 screen ,you can select the time countdown, calorie countdown or distance countdown.
Press mode to select the desired setting, then press speed up + or down – to change the value. Once selected
press start to begin exercise. The speed and incline can be changed manually whilst exercising, when in P1-P12
program ,the time window will display (30 minutes),this is the system default setting. The time will flash, if desired
press speed up + or speed down – to change, then press start to begin. When in the Body Fat function ,this is
used to change the F1,F2,F3,F4,FAT functions .
C: The speed is set to operate in Mph, however if you prefer to work in kph then please follow the processes below
to switch between the two.
1: Remove the safety key, then the computer will show E-07
2: Press and hold “program and mode” buttons together for 2 to 3 seconds
3: The console with change the speed from mph to kph automatically
D：”Start”, Press this key to start an exercise. If no program is selected P0 manual will begin.
E: ”
Stop”: When the treadmill is running Press the “stop” key and the machine will slow down and stop. All
functions on the LCD will be reset to zero.
F
: Speed+/-，adjusts the speed between 1-16KM
12
CONSOLE OPERATION
LCD DISPLAY
SPEED BUTTONS
INCLINE BUTTONS
STOP BUTTON
START BUTTON
MODE BUTTON
PROGRAM BUTTON
SPEED/PROGRA
M DISPLAY
TIME/DISTANCE/CALORIE
DISPLAY
PULSE/INCLINE
DISPLAY
SAFETY KEY
