REED 00 MODEL: C50SS
TRAILER CONCRETE PUMP
MAINT
PAGE 04
LUBRICATION
The 00 MODEL C50SS concrete pump is equipped with several components that because
of the application require frequent lubrication. These areas involve the S-tube shifting
mechanism, swing components, the shift and outlet bearings and agitator. To insure the
economical service and the long life of these components, grease fittings are installed at
each point.
Rapid wear and probable component breakdown will
result if the unit is operated with inadequate
lubrication. Follow the recommended interval and if
need be increase the interval when above normal
usage takes place.
LUBE POINT LOCATIONS
• Swing Tube Shift
• Quantity 1 at cylinder barrel pivot
• Quantity 2 at bell crank
• Quantity 2 at swing tube shaft bearing housing
• Swing Tube Outlet
• Quantity 2 on outlet bearing housing
• Agitator/Remixer
• Quantity 2 – On non motor end
• Quantity 1 – One on motor end
Recommended Lubricant: GENERAL PURPOSE GREASE, SHELL ALVANIA EPLFH2 or
EQUAL
Recommended Interval: DAILY, BEFORE START-UP AND AS REQUIRED DURING
OPERATION
REVISION:
