Glue the non-woven fabric to the roll in the winding direction and wind 3 layers.
Install the take-up reel in place and press down on the motor pin.
Pay attention to the shape of the pin, it has a special notch to prevent the motor from
slipping. Insert the roll by aligning the 2 pieces together.
