Reely Cheetah - Programming the Special Functions; Description of Programmed Special Functions; Undervoltage Protection (Cut-off Voltage); Cell Voltage for Undervoltage Protection

Proceed as follows:
• Placethemodelvehiclesothatthewheelscanturnfreely.Useasuitablebasisoracarstand.
• Takethetransmitterintooperation;insert,e.g.,batteries/rechargeablebatteriesandswitchonthetrans-
mitter.
 Leavethethrottle/brakeleverinitsneutralposition(donotmovethelever).Putthetrimmingfordrivinginto
the centre position.
• Connectafullychargeddrivebatterytothespeedcontrollerifyouhavenotdonesoalready.
• Keeptheoperatingbutton(9)pushedforafewseconds.ThemotoremitsalongbeepandtheLEDinthe
operatingbuttonashesred.Themotorthenemitscontinuousshortbeeps.
The sounds are generated by a short start-up of the brushless motor.
• Releasethethrottle/brakeatyourtransmittersothatitsitsintheneutralposition.
• Brieypushtheoperatingbutton(9);theLEDintheoperatingbuttonbrieyashes1xgreenandthemotor
emits a brief beep. The neutral position is now saved.
• Movethethrottle/brakeleveratthetransmittertofullthrottleforforwardsdriving,pullittowardsthehandle
and hold it there.
Attention!
 Ifyoudonotmovethetransmitterthrottle/brakeleverduringtheprogrammingprocessordonot
move it far enough, the vehicle might respond even to slight movements of the transmitter throttle
leverorbecomeuncontrollable.Inthatcase,repeatprogramming.
• Brieypushtheoperatingbutton(9);theLEDintheoperatingbuttonbrieyashes2xgreenandthemotor
emits two brief beeps. The full throttle position for forward driving is stored.
• Movethethrottle/brakeleverofthetransmittertofullthrottleforreversedriving,pushitawayfromthe
handle to the stop.
• Brieypushtheoperatingbutton(9);theLEDintheoperatingbuttonbrieyashes3xgreenandthemotor
emits two brief beeps. The full throttle position for reverse driving is stored.
• Releasethethrottle/brakesothatitsitsintheneutralposition.
• Ifyouwaitforafewsecondsnow,youwillleavesettingmodeautomaticallyandthespeedcontrollerwill
be ready for operation with the new settings the LED in the operating button is lit red.
b) Programming the Special Functions
All special functions of the speed controller can be programmed very simply and comfortably via the enc-
losed programing card.
Proceed as follows for programming:
• Placethemodelvehiclesothatthewheelscanturnfreely.Useasuitablebasisoracarstand.
• Takethetransmitterintooperation;insert,e.g.,batteries/rechargeablebatteriesandswitchonthetrans-
mitter.
 Leavethethrottle/brakeleverinitsneutralposition(donotmovethelever).Putthetrimmingfordrivinginto
the centre position.
• Connectafullychargeddrivebatterytothespeedcontrollerifyouhavenotdonesoalreadyorswitchoff
the speed controller.
• Connecttheprogramingcard(3)tothecorrespondingsocket(8)atthespeedcontrollerviatheenclosed
connectioncable(4).
 Alwaysensurecorrectpolarity.Acolourmarkorlabel„+“,„-“and„S“helpsmaketheproperconnection.
• Switchonthespeedcontrollerbybrieypushingtheoperatingbutton(9).Thentheprogrammingcard
shows the current programming by its LEDs.
• Brieypushingthebuttonontheprogramingcard(lowerright)permitsswitchingbetweenthedifferent
functions.Foradescriptionofthefunctions,seethenextchapter.
To change the current value, keep the button on the programming card pushed for a longer time. The LEDs
showtherespectivevalue;releasethebuttonagainwhenthedesiredvaluehasbeenset.TheLEDinthe
speedcontrollerthanbrieyashesgreen.
• Ifyouwanttoterminateprogramming,switchoffthespeedcontrollerbykeepingtheoperatingbutton(9)
pushed for one second.
 Thendisconnecttheprogrammingcardfromthespeedcontroller;pulltheconnectioncable(4)fromthe
socket (8) of the speed controller.
Description of the programmed special functions
Note:
When the programming card is connected to the speed controller, the motor is deactivated for
reasons of safety.
„Cut-off Voltage“ Function: Undervoltage protection
IfLiPorechargeablebatteriesareused,thenyoumustensurethatthelow-voltageprotectionisactivatedand
set correctly (we recommend at least 3.0 V per cell). When operating a LiPo battery without undervoltage
protectionorwhensettingtoolowavalue,theLiPobatteryispermanentlydamagedbydeepdischarge!
• „AutoLiPo“(automaticrecognitionofthecellnumber;basicsetting)
 ThespeedcontrollermeasuresthevoltageoftheconnectedLiPodrivebatterywhenswitchingon.Ituses
this voltage to calculate the cell number (e.g. 2 or 3 cells). Depending on the deactivation voltage set in
thefunction„Auto-LiPoCutoffVolts/Cell“,thespeedcontrollerswitchesoffthemotortopreventdeep
discharge of the LiPo rechargeable battery.
When this setting is chosen, connect a fully charged LiPo drive battery, but never a partially charged one.
Otherwise,thecorrectcellnumbercannotberecognisedcorrectly.
• „None“(noundervoltageprotection)
This setting must only be chosen if you operate the speed controller with a NiMH drive battery.
• „5V“,„6V“,„9V“,„12V“(xedvoltagevalue)
 Thesesettingscanbeusedtospecifyaxedvoltagevalueforundervoltageprotection.
 Thesetting„5V“must,however,notbeusedforany2-or3-cellLiPodrivebattery!
Function „Auto-LiPo Cut off Volts/Cell“: Cell voltage for undervoltage protection
Ifthesetting„AutoLiPo“ischoseninthefunction„CutOffVoltage“,youmustsetthecellvoltageherewhen
the speed controller is to switch off the motor.
The speed controller measures the voltage of the connected LiPo drive battery when switching on (this must
befullyloaded).Itusesthisvoltagetocalculatethecellnumber(e.g.2or3cells).
Ifyouhave,e.g.,connectedatwo-cellLiPodrivebatteryandsetavoltageof3.1V,thespeedcontroller
switchesthemotoroffatatotalvoltageof6.2V(2cellsx3.1V=6.2V).
Avalueof3.0V/cell,3.1V/cell,3.2V/cellor3.3V/cellispossible;thedefaultsettingis3.2V/cell.
Function „Drag Brake“: Motor brake
Ifyoureducethethrottleatthetransmitterormovebackthethrottle/brakeleverintotheneutralposition,
thevehiclewillslowdownautomatically.Theeffectisthusexactlylikethatofthemotor-brakingfunctionina
„real“ car when you release the throttle pedal without stepping on the brake pedal.
This also corresponds to the brake function of a conventional electric motor (a brushless electrical motor
does not have any strong magnets that brake the rotor).
Avaluefrom0%to30%canbesetinstepsof5%;thedefaultsettingis10%.
Function „Brakes Strength“: Brake force
The speed controller unit allows proportional braking strength depending on the setting of the transmitter
lever. A high setting (e.g. 100%) decreases braking distance but has a negative effect on the lifetime of the
drive(specicallyforthedrivepinionandthemaingear).Thebrakeisswitchedoffforthesetvalue„0%“.
Avaluefrom0%to100%canbesetinstepsof10%;thedefaultsettingis80%.
Function „Punch Strength“: Acceleration when starting to drive (start-up torque)
Dependingonthissetting,thetake-off/startspeedismoreorlesspowerful.Thehigherthesetvalue,the
morecurrentwillthemotorpullfromtheconnectedbattery;itmustaccordinglybeofhigherquality.
A higher setting also should only be used on loose underground, since otherwise there may be an overload
of the drive.
Thevaluecanbesetfrom0to30instepsof5;thedefaultsettingis10.
„Dead Band“ Function: Neutral position recognition range
Sethowhightheareaforrecognitionoftheneutralpositionatthetransmitteris.
Ahigherarea(„Large“)mustbesetwhenthemechanicsforthethrottle/brakeleveratthetransmitterworks
inaccurately.Forhigher-valuetransmitters,thesetting„Small“or„Normal“mustbeused.Thedefaultsetting
is „Normal“.
„Reverse Type“ function: Drive function
Inthisfunction,thedrivefunction(forward/reverse)andthebrakecanbeprogrammed.
• „ProportionalRev.LockOut“
 Reversedrivingisonlypossibleifthethrottle/brakeleveratthetransmitterhasbeenintheneutralposition
for2seconds.Otherwise,onlythebrakeisactivatedifyoumovethethrottle/brakeleveratthetransmitter
to the position for reverse driving.
• „Proportionalw/oReverse“(defaultsetting)
 Reversedrivingisdeactivated.Ifthethrottle/brakeleveratthetransmitterismovedtothepositionfor
reverse driving, the drive is only braked.
• „FWDtoBrakeandReverse“
 Bothforwardandreversedrivingorthebrakefunctionareactivated.
 Ifthethrottle/brakeleveratthetransmitterismovedwithoutpausefromforwardtoreversedriving,the
speedcontrolleractivatesthebrakefunction.Ifthethrottle/brakeleverisbrieyintheneutralposition
between forward and reverse driving or if the vehicle is standing, the vehicle will then drive backwards.
„Motor Timing“ Function: Brushless motor timing
Thissettinginuencesmotorrunningcharacteristics(similartoearlyignitionofacombustionengine).
You can change this setting in steps of 5° from „None“ (no timing change, 0°) via „Low“, „Middle“ to
„High“(30°).
Ifyouset„None/0°“,themotorhasalittlemoretorqueandalittlelowermaximumrotatingspeedthanin
thedefaultsetting(10°).Setting„High/30°“meansthatthemotorhasalittlehighermaximumspeedanda
little less torque.
Inbothcases,thecurrentvalueschangehowever.Additionallyobservethetemperaturesofthemotorand
speed controller in operation.
„ESC Type“ function: Speed controller type
This LED shows whether a motor with sensor connection has been recognised (such as the enclosed brush-
less motor with sensor cable).
„Motor Direction“ Function: Rotating direction of the motor
Withthisfunction,youcanswitchtherotatingdirectionofthemotorsothatthemovementatthethrottle/
brake lever of the transmitter matches the driving direction of the vehicle (depending on the gear of the model
vehicle).Thedefaultsettingis„Normal“;„Reverse“reversestherotatingdirection.
