Instruction Manual DIGIMON-SE / DIGIMON4 English
5
Property
Value
Maximum working
pressure:
Low pressure: 60bar / 870psi / 6000kPa / 6MPa
High pressure : 60bar / 870psi / 6000kPa / 6MPa
Pressure
resolution:
0.01 bar / 0.5psi / 1kPa / 0.001MPa
Pressure units:
bar / psi / kPa / MPa
Positive pressure
display:
0 to 60bar, up to 870psi, up to 6000kPa, up to 6MPa
Negative pressure
display:
0 to -0.95bar, 0 to -13.7psi, 0 to -95kPa, 0 to -0.095MPa
Accuracy class:
Class 1.0
External
thermocouple:
Temperature range:
-40°C to +125°C / -40°F to +257°F
Plug:
K-type
Accuracy of
measurement:
+/- 1°K
Resolution:
0.1°C / 0.1°F
Optional clamp
thermocouple K-
type
Temperature range:
-40°C to +125°C / -40°F to +257°F
For pipe diameters of:
6mm to 38mm / ¼“ to 1 ½“
Plug:
K-type
Accuracy of
measurement:
+/- 1°K
Resolution:
0.1°C / 0.1°F
Ambient
temperature:
0°C to +50°C / +32°F to +122°
Power supply:
4 x 1.5 V AA / Mignon / LR6 batteries
Service life of approx. 50 hours when used continuously.
Storage
temperature:
- 20°C to + 60°C / -4°F to 140°F
Vacuum display without vacuum sensor
Property
Value
Vacuum display:
Bar diagram display
1 bar ca. 0 to -300mbar
2 bars ca. -300 to -380mbar
3 bars ca. -380 to -460mbar
4 bars ca. -460 to -540mbar
5 bars ca. -540 to -620mbar
6 bars ca. -620 to -700mbar
7 bars ca. -700 to -780mbar
8 bars ca. -780 to -860mbar
9 bars ca. -860 to -920mbar
10 bars ca. -920 to ultimate vacuum
