Reflexion DVD1052 - Page 22

22
14
15
Second monitor
Main monitor
Second monitor
1. On / off
14. DC In
2. SD / MMC card slot
15. AV input
3. USB
16. Headphone socket
4. Headphone socket
17. On / off
5. Video / Audio output
18. / UP
6. Video / Audio input
19. / DOWN
7. Power output
20. MODE
8. DC IN 9 - 12V
21. LEFT / Volume -
9. Navigation buttons (up / left)
22. RIGHT / Volume +
10. Navigation buttons (down / right)
11. SOURCE (input signal selection)
12. (Play/Pause)
13. (STOP)
16
17
18 19 20 21 22
