REFU Elektronik GmbH REFUsol 08K ... 23K 33
Ethernet
Inverter 1
Inverter 2 Inverter n
Eth2 Eth3 ... Eth n
Ethernet Ethernet Ethernet
Fig. 19: Ethernet interface
NOTICE
In order to ensure IP 65 protection, the plug type mentioned above must be used.
Failure to observe this can lead to damage to the inverter and therefore void the
warranty.
