How to fix PM isolation LT error on REFU REFUsol 08K Inverter?
If your REFU Inverter shows a PM isolation LT error, it means the power section detects an isolation error on activation. Check system isolation. If you consider the isolation resistance to be in order, contact Service.
What does Keep Alive mean on REFU REFUsol 08K?
If your REFU Inverter displays Keep Alive error, it means internal communication monitoring has determined a fault. Please contact Service.
What to do if REFU REFUsol 08K displays SR parameter error?
If your REFU Inverter displays an SR parameter error, it signifies an error in parameter initialization, and the device has been permanently shut down. Please contact Service.
What to do if REFU REFUsol 08K showing update fault?
If your REFU Inverter displays an update fault, it means the update has failed. Contact Service.
What to do if REFU REFUsol 08K Inverter shows Supply voltage LT error?
If your REFU Inverter displays a Supply voltage LT error, it means the supply voltage at the power section is too low. Please contact Service.
What does Activation LT 4 mean on REFU REFUsol 08K Inverter?
If your REFU Inverter displays Activation LT 4 error, it means balancing has failed. Please contact Service.
How to resolve Initialisation C1 error on REFU REFUsol 08K?
If your REFU Inverter displays an Initialisation C1 error, restart the inverter. If this does not rectify the error, contact Service.
What to do if REFU Inverter shows DC-voltage measurement error?
If your REFU Inverter displays a DC-voltage measurement error (DC link 3), wait for the measurements to become stable again. If this takes more than 2-3 hours, please contact Service.
What does Communication LT mean on REFU REFUsol 08K Inverter?
If your REFU Inverter shows Communication LT error, it means there is a communication malfunction between the power section and the control and regulation unit. The inverter will acknowledge the error automatically. If the problem occurs repeatedly, contact Service.
What to do if REFU REFUsol 08K shows RCD fault?
If the AFI-Board unit in your REFU Inverter detects a residual current, it will lead to an immediate shutdown. Check the system isolation. If you believe the isolation impedance is fine, contact Service.
Specifies the required professional qualifications for personnel working with the inverter.
Details potential hazards and risks associated with improper use of the inverter.
Outlines safety measures to prevent injury from electrical components.
Warns about the danger of burns from hot surfaces on the inverter housing.
Provides guidelines for safe handling and assembly to prevent injuries.
Explains how to connect the DC power source (PV generator) to the inverter.
Defines criteria for the installation location, including safety and environmental considerations.
General instructions for mounting and installing the inverter onto a wall-mounting plate.
Identifies and describes the various connectors on the inverter's bottom side.
Explains the importance and procedure for grounding the inverter for safety and EMC compliance.
Details the steps and safety precautions for connecting the inverter to the AC power supply.
Step-by-step instructions for powering up the inverter after installation.
Explains the sequence and indicators during the inverter's self-test and activation.
Details how faults are detected, indicated, and stored in the fault memory.
Procedure for acknowledging faults to allow the inverter to reactivate.
General| Rated Power | 8 kW |
|---|---|
| Max. input voltage | 1000 V |
| Number of MPP Trackers | 2 |
| AC nominal voltage | 400 V |
| Frequency Range | 50 Hz / 60 Hz |
| Cooling Method | Convection |
| Protection class | I |
| Protection Degree | IP65 |
| Max. apparent AC power | 8000 VA |
| MPP voltage range | 350 V to 800 V |
| MPPT Range | 350 V to 800 V |
| Output Voltage | 400 V |
| AC Voltage Range | 310 V - 480 V |
| Operating Temperature Range | -25°C to +60°C |
