Connect PHOENIX CONTACT connector (SUNCLIX)
DANGER
Danger to life due to high voltages from active PV strings
The SUNCLIX connectors are only to be connected by electrotechnically
trained personnel.
Never connect or disconnect SUNCLIX connectors when under load.
CAUTION
Danger of injury or damage to property
Only use the SUNCLIX connectors together with a PV1-F type 2.5-6 mm
2
cable or UL-certified solar cable (ZKLA stranded copper wire, AWG 10-14). A
safe electrical connection is only guaranteed with this cable. Further cable
types can be requested from PHOENIX CONTACT.
When laying the solar cable, observe the bend radii specified by the
manufacturer.
Only connect the connectors to other SUNCLIX connectors.
When connecting, always observe the specifications for rated voltage and
rated current. The smallest mutual value is valid.
Protect the connector against moisture and dirt.
Do not submerge the connectors under water.
Do not lay the plug directly on the roofing.
Protect unplugged connectors with a protective cap (e.g. PV-C PROTECTION
CAP, 1785430
).
4.13.2.1
Connect cable
1. Strip the cable by 15 mm with a suitable tool. Ensure no individual strands are cut off.
2. Carefully add stripped conductors with drilled bunched conductors until impact. The bunched conductor
ends must be visible in the spring.
3. Close spring. Ensure that the spring is locked in place.
4. Push insert into the barrel.
5. Tighten the cable screws with 2 Nm.
6. Bring together plug and bush. The connection latches.
7. By pulling the coupler, check the correct connection.
