REFU Elektronik GmbH REFUsol 08K ... 23K 63
TYPE Si-13TC-T-K
Exterior dimension W x H x D (mm / in)
145 x 81 x 40 mm (5.71″ x 3.19″ x 1.57″)
Weight
340 g (0.75 lbs)
INSOLATION
Measuring range 0 – 1,300 W/m²
Output signal
0 to 10 V
Measuring accuracy
±5 % of final value
MODULE TEMPERATURE
Measuring range -20 – +90 °C (-4 – 194 °F)
Output signal 2.268 V + T [°C]* 86.9 mV/°C
Measuring accuracy
±1.5 % at 25 °C (77 °F)
Non-linearity
0.5 °C (32.9 °F)
Max. deviation
2 °C (35.6 °F)
PIN ASSIGNMENT
Orange
Measurement signal for insolation (0 to 10 V)
Red
Supply voltage (12 – 24 VDC)
Black
GND
Brown
Measurement signal for temperature (0 – 10 V)
Power supply Temperature and radiation sensor or PowerCap
