9
Brio-
R
SPECIFICATIONS
Input sensitivities for rated output level:
Input 1 (Phono) input sensitivity = 2.1mV at 47KΩ In p a ra lle l w i th 2 20 p F .
Maximum Input 1 (Phono) input level = 100mV.
Input 2 to 5 (Line) input sensitivity = 210mV at 47K.
Maximum Input 2 to 5 (Line) input level = 10.25V
Power outputs at 230/115V supply voltage:
50Watts RMS both channels driven into the rated load of 8Ω .
58Watts RMS one channel driven into the rated load of 8Ω .
73Watts RMS both channels driven into the rated load of 4Ω .
93Watts RMS one channel driven into the rated load of 4Ω .
Continued high level use into 4Ω may cause the case to exceed 40° C above the ambient
temperature.
Power consumption:
195Watts at 230/115V into the rated load of 8Ω .
Record output level:
Record output level (with rated input levels) = 210mV.
Record output impedance = 470Ω .
Frequency response:
Phono 15Hz to 40KHz (-3dB points) / 27Hz to 20.5KHz (-1dB points).
RIAA accuracy (100Hz to 10KHz) ± 0.4dB typically better than ± 0.3dB
Line 12Hz (-1dB points) to 43KHz (-3dB points).
