CHAPTER 8
8-4
DC ELECTRICAL DIAGNOSTIC CHART
PROBLEM POSSIBLE CAUSE POSSIBLE FIX
No 12 volt power
Battery switch in "off"
position
Weak or dead battery
Turn selector switch to
"on" position
Charge or replace
battery
Battery not charging;
(Engine running)
Loose belt
Faulty alternator
Faulty volt meter
Tighten belt
Repair/Replace
alternator
Replace volt meter
Battery will not hold
charge
Faulty/Old battery Replace battery
12 volt equipment not
working
Equipment switch "off"
Circuit breaker blown
Weak or dead battery
Corroded connection
Loose wire
Internal equipment
short
Switch to "on" position
Push reset on circuit
breaker
Replace battery
Eliminate corrosion
Tighten connection
Replace equipment
