Regal 2300 - Fuel System

1-1/8" BILGE FLEX HOSE- 8FT
DESCRIPTION
1
1
3/8" FUEL CARB - 3FT
QTY.
1
01
03
1776
1463
PART #
04
17691-1/2" FUEL FILL HOSE - 8FT
02
BILL OF MATERIALS
5/8" FUEL VENT HOSE- 8FT
ITEM
1
1770
FUEL TANK
NOTE: DO NOT STRAP HOSES TOGETHER.
BILGE THRU HULL
TO ENGINE
FUEL FILL
BILGE PUMP
FUEL VENT
DATE:
REVISION DESCRIPTION
REGAL MARINE INDUSTRIES
MDR23A
12.12.08
2300 Fuel Plumbing
2300 Fuel Plumbing
DR. BY
ALL RIGHTS RESERVED
1 of 1
REV. DATE
2300 JETPORT DRIVE
ORLANDO, FLORIDA 3280 9
TEL (407) 851-4360
APP. BY
DWG. NO.:
APPROVED BY:
DRAWING TITLE:
DRAWN BY:
RYAN.WB
Page:
D. Linder
2300 FUEL SYSTEM
12-11
