72
Chapter 4
TYPICAL 12 VOLT HELM BREAKER PANEL
HORN- protects the horn circuitry.
SPOT LT- protects the deck mounted spot/search light.
TRIM TABS- protects the transom mounted electric-
hydraulic trim tab circuit.
NAV LTS.- protects the port and starboard deck naviga-
tion lights.
COCKPIT LTS- activates the LED cockpit lights in-
stalled on the deck.
HIGH WATER ALARM- protects the helm mounted
alarm. Part of the system including the sensor oat is
located in the engine room.
.
WIPER- protects windshield wiper circuit.
WINDLASS- protects the deck mounted foot petals.
EXH BLOWER- protects the head exhaust fan.
VAPOR DETECT- protects the gas vapor detector op-
tion located in the bilge.
COCKPIT FRIDGE- protects optional refrigerator cir-
cuitry.
PLOTTER- protects the optional chart plotter system.
BILGE LIGHTS- controls lights in the engine room.
UNDERWATER LTS.- protects the transom mounted
light (under platform) circuit.
HALON- protects the halon re extinguishing system
located in the bilge.
DOCKING LTS.- protects the hull mounted docking
light circuitry.
ARCH LT.- protects the power tower actuator circuitry.
AFT BILGE PUMP- protects the bilge pump in the
engine room.
ACCESSORY 1 & 2- protects any optional equipment.
VHF RADIO- protects the marine radio circuitry.
GPS (FUSE)- protects the GPS chart plotter circuitry.
NEUTRA SALT- Protects the neutral salt engine re-
lated circuitry.
12 VOLT RECEPTACLE PLUG- protects plug-in cir-
cuitry.
12 VOLT RECEPTACLE PLUG- protects plug-in cir-
cuitry.
