TYPICAL D.C. DISTRIBUTION CENTER-COMPONENT BREAKER DESCRIPTION
DASH MAIN- protects dash operation switch functions,
and engine hatch panel. In addition, it controls compo-
nents located on the helm breaker sub-panel. Engine
functions are not controlled by the dash main breaker.
CABIN MAIN- protects the cabin main DC panel
which controls direct current switch functions through-
out the vessel.
WINDLASS- protects the deck mounted anchor wind-
lass circuitry.
ELECTRONICS- protects all electronic dash equip-
ment components along with the stereo components.
In addition, this breaker controls all breakers from the
electronics through sirius weather on the helm breaker
panel.
AFT BILGE PUMP- protects the aft bilge pump fl oat
switch circuitry located in the engine room.
HIGH WATER ALARM- protects the bilge high wa-
ter alarm. This audible alarm sounds at the dash should
bilge water reaches a predetermined level. Normally this
would indicate large volumes of water are entering the
bilge since normal amounts would be drawn overboard
via the bilge pump system.
FWD. BILGE PUMP- protects the forward most bilge
pump fl oat switch circuitry.
OIL CHANGER- protects the engine and generator oil
changer pump circuitry located in the bilge.
STEREO MEMORY- protects the stereo system mem-
ory circuit and the stereo unit itself.
SHOWER SUMP PUMP- protects the aft/forward
shower sump pump circuitry.
