70
Chapter 7
SPOTLIGHT
Joystick
The spotlight fea-
ture a 20,000 candle
power light beam
which can penetrate
up to over 1/2 a
mile in ideal condi-
tions. The 2 speed
searchlight provides
up to 370º horizon-
tal rotation and up
to 135º vertical tilt
with a dash mounted fi ngertip control pad. The bulb pro-
vides superior light penetration. Included is a protective
lens cover.
Note that the searchlight is a radio transmitter and oper-
ates at 433Mhz. When the light is activated, the internally
mounted antenna sends out radio frequency (RF) energy.
Note that it is possible that this component could affect
other electronic equipment. Refer to operator’s manual for
possible solutions should this occur.
Operation-
1. Using the dash mounted remote control, turn the unit
on by depressing the on/off button.
2. Using the same dash mounted remote control, rotate
your light to the desired location.
3. The light speed can be controlled by depressing the fast/
slow button one time and by depressing it again to restore
the original speed.
4. The light should not be turned on when the snap on
lens is attached. The hard wired dash control will be backlit
when the bulb is illuminated.
The dedicated circuit is uses a 10 amp breaker on the power
side for overcurrent protection.
The unit uses a Phillips 9011 bulb replaceable from Go-
light, Inc. at 800-557-0098.
Directional-
Buttons
On-Off
(Power)
Button
Fast/Slow
Buttons
Note: If you remove the rubber cover from the helm
control pad you will see 2 batteries. Should the unit not
function correctly replace with 12 volt alkaline batteries.
When purchasing check for correct type and amperage.
Helm Control Pad
