41
Systems
12 VOLT HELM BREAKER SUB PANEL DESCRIPTION
HORN- protects the air horn located on the hardtop.
NAV LTS- protects the port and starboard deck naviga-
tion for night cruising.
PANEL LTS- protects the helm (dash) back-lighted
icons.
WINDLASS- protects the windlass deck mounted foot
switches.
NIGHT LTS- protects the 2 forward cockpit ceiling
lights.
PARALLEL- protects the battery parallel wiring system.
SUNROOF- protects the open and close helm mounted
switch.
MARETRON- This breaker is currently inactive.
PORT WIPER- protects port windshield wiper circuit.
STBD. WIPER- protects the starboard windshield wip-
er circuit.
CAMERA 1-3- protects the camera circuits. 4 not used.
AFT BILGE PUMP- protects the aft engine room bilge
pump.
HARDTOP LTS.- protects the sunroof ceiling lights.
COCKPIT LTS.- protects the cockpit installed light cir-
cuit.
UNDERWATER LTS.- protects the transom mounted
LED light (under platform) circuit.
DECK LTS.- protects the deck light circuit.
WINDSHIELD VENT- protects the fresh air wind-
shield vents.
TENDER LIFT- protects the lift circuitry.
COCKPIT ACC.- protects accessory switch on icemak-
er switch panel.
FWD TABLE- protects the table lift circuitry.
BILGE LTS.- protects the garage and engine room light
circuitry.
COCKPIT STEREO- protects the dash stereo power
circuit.
COURTESY LTS.- protects the stairway soft lights.
DE FOG FAN- protects the driver side blower fan.
ACC 1- protects aftermarket accessory circuit.
DE-FOG FAN- protects the windshield defogging sys-
tem.
SUN SHADE- protects the sun shade switch circuitry.
SUN SHADE- protects the sun shade ram circuitry.
ELECTRONIC- protects the dash electronics switch.
DEPTH SOUNDER- protects the dash mounted depth
sounder.
VHF- protects the marine radio circuitry.
