Regal SMARTVALVES - Page 31

DRAWING NO. 14 — 7500 REMOTE METER PANEL ASSEMBLY
for 10 to 500 PPD Systems for CL
2
and SO
2
only
NOTE:
If system is using 1000 PPD or 2000 PPD Remote Metering Panel
Assembly, refer to the Instruction Manual for information on these
high capacity gas feed systems.
Quantity
1
1
1
1
1
1
2
2
2
2
2
4
1
2
Description
Meter Type Assembly
Base Plate
Bottom Block
Top Block
Meter Tube Plug
Rate Valve Plug Assembly
Top and Bottom Bushing
Top and Bottom Bushing
Gasket
Top and Bottom Meter Tube
Gasket
Rate Valve Plug O-Ring
Meter Tube Plug O-Ring
Screw, 1/4-20 x 1" Long
Plug, 1/2" NPT
Tube Fitting, Elbow (Not Shown)
Part No.
See chart
7502
7503
7504
7505
RV-831
See chart
G-700
See chart
S-403
S-406
Z-815
ZZ-278
See chart
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
REF 10 PPD 25 PPD 50 PPD 100 PPD 250 PPD 500 PPD
NO. (200 (500 (900 (1900 (5000 (10
gms/hr) gms/hr) gms/hr) gms/hr) gms/hr) kg/hr)
1 7501-10 7501-25 7501-50 7501-100 7501-250 7501-500
7 7507 7508 7508 7508 7509 7510
9 G-701 G-702 G-702 G-702 G-703 G-704
14 ZZ-275 ZZ-275 ZZ-275 ZZ-275 ZZ-276 ZZ-277
31
