Step 1 : Remove crib rail from packaging and set all parts out in front of you.
Step 3 : Repeat Step 2 directions to assemble the right side of the crib rail.
(Diagram A2)
Step 2 : Insert Left Upper Support Bar into Left Bottom Support Bar. Make sure the
spring pin fits securely into opposing hole so that the two pieces cannot pull apart.
(Diagram A1)
CRIB RAIL ASSEMBLY AND SET UP
Step 4 : With the left and right sides of the crib rail assembled, connect the two
sides. (Diagram B1)
NOTE : Make sure that the spring pins are secured into the opposing holes so that
the crib rail cannot pull apart.
(Diagram B1)
(Diagram A1)
(Diagram A2)
