Step 1 : Remove bed rail from packaging and ensure that you have all parts included
in the parts list.
Step 3 : Repeat Step 2 directions to assemble the right side of the bed rail.
(Diagram A2)
Step 2 : Insert the Left Upper Support Bar into the Left Bottom Support Bar. Make sure the
spring pin fits securely into opposing hole so that the two pieces cannot pull apart.
(Diagram A1)
BED RAIL ASSEMBLY AND SET UP
Step 4 : With the left and right sides of the bed rail assembled, connect the two
sides.
(Diagram A3)
NOTE : Make sure that the spring pins are secured into the opposing holes so that
the bed rail cannot pull apart.
(Diagram A1)
(Diagram A2)
(Diagram A3)
