Regency F2100M - Parts List - Pedestal, Bottom Shield and Legs

Regency Freestanding Woodstove
24
PARTS LIST
1) 846-913 Door Assy- Medium Gold S2100 (no glass)
846-915 Door Assy-Medium Black S2100 (no glass)
846-910 Door Assy-Large Gold S3100 (no glass)
846-916 Door Assy-Large Black S3100 (no glass)
3) 846-302 Glass - Replacement - Medium - S2100
846-304 Glass - Replacement - Large - S3100
4) 936-243 7/8" Adhesive Tape Gasket
5) 846-920 Glass Retainer Clips (8/set)
6) * Screw - 1/4 - 20 x 3/8"
7) 948-170/P Small Glass Retainer - S2100
948-172/P Large Glass Retainer - S3100
8) 130-006 Side Panel - Right - S2100
130-005 Side Panel - Left - S2100
150-006 Side Panel - Right - S3100
150-005 Side Panel - Left - S3100
9) 846-973 Door Handle Assembly
16) 846-570 7/8" Door Gasket Repair Kit
Part # Description Part # Description
17) 846-918 Hinge Cap - Gold (2/set)
19) 948-101 Spring Handle - Large
20) 948-102 Spring Handle - Small
846-515 Complete Fan/Blower Assy (120 V)
25) 910-684 Power Cord (120 V)
27) 910-142 Thermodisc Fan Auto ON/OFF
28) 910-138 Manual/Auto Switch (2-way)
29) 910-140 Fan Speed Switch HI/OFF/LOW (3-way)
30) 910-157/P Fan/Blower Motor (120 V)
35) 063-954 Air Tube - S3100 (Qty:1)
36) 033-953 Air Tube - 3/4" S2100 (Qty: 3)
063-953 Air Tube - 1" S3100 (Qty: 3)
37) 033-955 Baffle (set) S2100
063-955 Baffle (set) S3100
908-288 Manual
*Not available as a replacement part.
S2100 & S3100 STEP STOVE MAIN ASSEMBLY
