F3500 Wood Stove | 3
*8
*8
8
8
*
*
*
*
FLOOR PROTECTION
(EMBER PROTECTION ONLY
REQUIRED)
A combustible oor must be protected by non-combustible
material (like tile, concrete board, or certied to UL-1618 or
as dened by local codes) extending beneath the heater and
a minimum of 8" (203mm) from each side and minimum 16"
(406mm) from the front face of the stove and minimum 6" (or
the rear clearance to combustibles whichever is smaller) from
the rear of the stove.
NOTE: This clearance is also required for air space between the
appliance and wall/ceiling. Where the appliance is installed less
than 8" from a rear wall, the ember pad only needs to extend to
the base of the wall based on the clearances noted in this manual.
When installed with horizontal venting, non-combustible oor
protection must beneath the ue pipe and extend 2" (51mm)
beyond each side.
Minimum Overall Width (X) of Floor
Protector for all installations:
Stove F3500 33" (838mm)
NOTE: In Canada, oor protection must extend 18" (450mm) to
the front and 8" (203mm) to each side (measured from fuel
door) and back of the stove.
Minimum Overall Depth (Y) of Floor Protector
Unit Residential
Close Clearance
Mobile Home
Close Clearance
Alcove
F3500
Y Z Y Z Y Z
USA
46-1/2" 8" 46-1/2 8" 46-1/2 8"
Canada
48-1/2" 8" 48-1/2" 8" 48-1/2" 8"
The rear clearance to combustibles is less than 6" (for corner installations the rear
corners may be angled to take advantage of the closer clearances.
NOTE: USA clearances shown above.
Minimum Overall Depth (Y) of Floor Protector - Corner Hearth
Reference only when hearth pad is installed to rear wall at minimum pipe clearances.
Hearth Depth
F3500 L M N O
Residential Installation ''C'' Vent (Single Wall)
Canada 33" (838mm) 65" (1651mm) 57-9/16" (1461mm) 25-3/4" (654mm)
USA 33" (838mm) 63" (1600mm) 56-1/8" (1425mm) 24-5/16" (618mm)
Residential Close Clearance (To be installed with required pipe components)
Canada 33" (838mm) 65" (1651mm) 57-9/16" (1461mm) 25-3/4" (654mm)
USA 33" (838mm) 63" (1600mm) 56-1/8" (1425mm) 24-5/16" (618mm)
M
O
L
N
*Measurement is taken from fuel door opening.
