Establishing a wireless connection to the Internet
In order to connect the base to the Internet, it is neces-
sary to enter the access data of the wireless LAN
network (the router). To do this, follow the steps in
chapter 5 to get to the input field for the access data.
Then perform the following steps:
1
On the integrated web pages, go to the IT Settings
menu item.
2
Enter the SSID and the password (WPA key) of the
wireless LAN network and confirm the entry.
3
Press both arrow buttons at the same time for
> 3 seconds
The WIFI/LAN LED and/or the AP LED will begin to
flash.
OK ><
> 3 sec
RZ12 COOL ZBUS1
DI4 WIFI/LAN
RZ11
DI3 AP
Confirm by briefly pressing the OK button. The current
status of the transmitting function is displayed.
4
By briefly pressing the right arrow button, it is possible
to switch between the transmitting functions (none,
direct connection, server connection). Press the right
button repeatedly until the direct connection is acti-
vated. In this case, the WIFI/LAN LED flashes and
the AP LED lights up permanently.
5
Confirm by briefly pressing the OK button.
6
The WIFI/LAN LED will start to light up permanently
after no more than 2 minutes. The base station is
now connected to the Internet and the REHAU server.
WIFI/LAN AP
WIFI/LAN AP
WIFI/LAN AP
WIFI and LAN o
Cloud Mode
Access Point Mode
APWIFI/LAN
OK ><
< 1 sec
APWIFI/LAN
End user manual 25
