USER GUIDE
DOCUMENT CONVENTIONS
SMART-SENSOR
™
DOCUMENT CONVENTIONS
This document features several conventions to help you learn the material and
procedures. These conventions are outlined below.
Bold-faced type for Window Title Bars.
e.g., The Inputs worksheet is open.
Initial capitals for Field Names and Buttons.
e.g., The value of the Panel Program field is pan. Click the Save button.
Italics in lowercase for field values, file types, directories, and file paths.
e.g., The value of the Panel Program field is pan.
The pan files are stored in the pan subdirectory of the job directory.
Italics in initial uppercase for Mode Types.
e.g., Toggle the Mode button to switch to Update mode.
Chevrons denote menu items.
e.g., To exit, select Access > Bye from the main menu.
All uppercase for KEYWORDS and Control-BASIC STATEMENTS.
e.g., Click ALARMS to open the Current Alarms worksheet.
Underscore connectors for section references.
e.g., Refer to Reference_Alarms_Alarm Configuration more details.
