After the appropriate onboard configuration tool has been invoked, the three-button key
pad is used to perform the necessary configuration of the SS-L or connected controller.
The and buttons are used to increase or decrease analog values or to change the
state of binary values displayed on the LCD. The button is used to step through the
configuration parameters.
SS-L ADDRESS TOOL
The onboard SS-L Address Tool is used to configure the SMART-Net
™
address of the SS-
L and the secondary point.
TO USE THE SS-L ADDRESS TOOL
1 Access the SS-L Address Tool using the appropriate key code combination
outlined in Table 17.
2
SSLADDR will display the value of the SMART-Net
™
address of the SS-L. Press
the or button to select the desired SMART-Net
™
address between 1–16.
3
Press the button to scroll to the 2DISP screen to display the SS-L point that is
selected to be shown as the secondary point. Press the or button to
select the desired point to be displayed as the secondary point.
4 After the SS-L Address and secondary point are configured as desired, allow the
onboard configuration tool to time-out. The LCD screen will revert to the Idle
mode.
