4.
Thread
Size
Nominal
Orifice
Inch
(mm)
Sprinkler
Temp.
Rating
Max.
Pressure
psi
(bar)
Max.
Ambient
Temp.
Actual
K
Factor
Sprinkler
Length
Inch
(mm)
°F °C °F °C
1
2
² NPT
(R
1
2
)
7
16
" (11)
155
175
68
79
175 (12)
100
150
38
66
4.9 2.25 (57)
Max. Sprinkler
Spacing
ft (m)
Flow
gpm (Lpm)
Pressure
psi (bar)
Sprinkler
Identification
Number (SIN)
12 x 12 (3.6x3.6) 13 (49) 7.0 (0.48)
R3516
14 x 14 (4.3x4.3) 13 (49) 7.0 (0.48)
16 x 16 (4.9x4.9) 13 (49) 7.0 (0.48)
18 x 18 (5.5x5.5) 17 (64.3) 12.0 (0.83)
20 x 20 (6.1x6.1) 20 (75.7) 16.7 (1.14)
Deflector - to - ceiling
Maximum 1² (25mm) to 4² (100mm)
Type
Adjustment
Inch (mm)
“A”
Inch (mm)
Face of fitting to
ceiling
Inch (mm)
F1
3
4
(19.0)
Min.=
3
4
² (19.1)
Max.=1
1
2
² (38.1)
3
16
-
15
16
(4.7 - 24.0)
F2
1
2
(12.7)
Min.=
15
16
² (23.8)
Max.=1
1
2
² (38.1)
3
16
-
11
16
(4.7 - 17.4)
Escutcheon*, F1 or F2, Data:
* Note:
Max. Sprinkler
Spacing
ft (m)
Flow
gpm (Lpm)
Pressure
psi (bar)
Sprinkler
Identification
Number (SIN)
12 x 12 (3.6x3.6) 15 (57) 9.4 (0.65)
R3516
14 x 14 (4.3x4.3) 16 (60.5) 10.6 (0.73)
16 x 16 (4.9x4.9) 17 (64.3) 12.0 (0.83)
18 x 18 (5.5x5.5) 19 (72) 15.0 (1.0)
20 x 20 (6.1x6.1) 22 (83.2) 20.2 (1.4)
*Deflector - to - ceiling
Maximum 4² (100mm) to 8² (203mm)
*Note: The F1 Res 49 pendent and recessed pendent
residential sprinklers can be installed per NFPA 13 in
beamed ceilings meeting the following criteria:
1. Maximum b eam depth = 7² (178mm)
2. Beam spacing at or greater than 7.5 ft. (2.3m) on center.
Technical Data: F1 Res 49 Pendent and Recessed Pendent
Thread
Size
Nominal
Orifice
Inch
(mm)
Sprinkler
Temp.
Rating
Max.
Pressure
psi
(bar)
Max.
Ambient
Temp.
K
Factor
Sprinkler
Length
Inch
(mm)
°F °C °F °C
½² NPT
(R½)
1
2
" (13)
155
175
68
79
175 (12)
100
150
38
66
5.8 2.25 (57)
Max. Sprinkler
Spacing
ft (m)
Flow
gpm (Lpm)
Pressure
psi (bar)
Ceiling -to-
Deflector
Inch (mm)
Sprinkler
Identification
Number (SIN)
12 x 12 (3.6x3.6) 16 (61) 7.6 (0.53)
1-4
(25-100)
R3513
14 x 14 (4.3x4.3) 16 (61) 7.6 (0.53)
16 x 16 (4.9x4.9) 16 (61) 7.6 (0.53)
18 x 18 (5.5x5.5) 19 (72) 10.8 (0.75)
20 x 20 (6.1x6.1) 22 (83.3) 14.4 (1.0)
Technical Data: F1 Res 58 Pendent and Recessed Pendent
**Baseline flows and pressures for 0.05 density
**Baseline flows and pressures for 0.05 density
**Calculate for a .10 density but in no case
go below the baseline flows & p ressures
