Reliable F1 - Page 7

Model F1 Res 44 & 58 HSW
Model F1 Res 44 & 58
Recessed HSW/F2
F2 escutcheon,
1
2
² (13mm)
adjustment
Thread
Size
Nominal
Orifice
Inch
(mm)
Sprinkler
Temp.
Rating
Max.
Pressure
psi
(bar)
Max.
Ambient
Temp.
K
Factor
Sprinkler
Length
Inch
(mm)
°F °C °F °C
½² NPT
(R½)
3
8
" (10)
155
175
68
79
175 (12)
100
150
38
66
4.4 2.45 (62)
Type
Adjustment
Inch (mm)
Face of Fitting
to wall
Inch (mm)
F2
1
2
(13)
3
16
-
11
16
(4.7 - 17.4)
Escutcheon, F2, Data:
Technical Data: F1 Res 44 HSW & HSW/F2
Max. Sprinkler
Spacing
ft (m)
“A”
Ceiling -to-
Deflector
Inch (mm)
Sprinkler Temp.
Rating
°F(°C)
Flow
gpm
(Lpm)
Pressure
psi (bar)
Sprinkler
Identification
Number (SIN)
12 x 12 (3.6x3.6)
4-6
(101-152)
155 (68) 175 (79) 12 (45.4) 7.5 (0.52)
R3531
14 x 14 (4.3x4.3) 155 (68) 175 (79) 14 (53.0) 10.2 (0.71)
16 x 16 (4.9x4.9) 155 (68) 175 (79) 16 (60.6) 13.3 (0.92)
16 x 18 (4.9x5.5) 155 (68) 175 (79) 18 (68.1) 16.8 (1.16)
18 x 18 (5.5x5.5) 155 (68) 175 (79) 19 (72.0) 18.7 (1.29)
16 x 20 (4.9x6.1) 155 (68) 175 (79) 23 (87.1) 27.4 (1.89)
12 x 12 (3.6x3.6)
6-12
(152-305)
155 (68) 175 (79) 14 (53.0) 10.2 (0.71)
14 x 14 (4.3x4.3) 155 (68) 175 (79) 16 (60.6) 13.3 (0.92)
16 x 16 (4.9x4.9) 155 (68) 175 (79) 17 (64.4) 15.0 (1.04)
16 x 18 (4.9x5.5) 155 (68) 175 (79) 20 (75.7) 20.7 (1.43)
16 x 20 (4.9x6.1) 155 (68) 175 (79) 23 (87.1) 27.4 (1.89)
*Baseline flows and pressures for 0.05 density
*Calculate for a . 10 density b ut in no case
go below the baseline flows & p ressures
7.
