Reliable F1 - Page 9

Thread
Size
Nominal
Orifice
Inch
(mm)
Sprinkler
Temp.
Rating
Max.
Pressure
psi
(bar)
Max.
Ambient
Temp.
K
Factor
Sprinkler
Length
Inch
(mm)
°F °C °F °C
½² NPT
(R½)
1
2
" (13)
155
175
68
79
175 (12)
100
150
38
66
5.8 2.45 (62)
Type
Adjustment
Inch (mm)
Face of Fitting
to wall
Inch (mm)
F2
1
2
(13)
3
16
-
11
16
(4.7 - 17.4)
Escutcheon, F2, Data:
Technical Data: F1 Res 58 HSW & HSW/F2
Max. Sprinkler
Spacing
ft (m)
“A”
Ceiling -to-
Deflector
Inch (mm)
Sprinkler Temp.
Rating
°F(°C)
Flow
gpm
(Lpm)
Pressure
psi (bar)
Sprinkler
Identification
Number (SIN)
12 x 12 (3.6x3.6)
4-6
(101-152)
155 (68) 175 (79) 16 (60.6) 7.6 (0.53)
R3533
14 x 14 (4.3x4.3) 155 (68) 175 (79) 18 (68.2) 9.7 (0.67)
16 x 16 (4.9x4.9) 155 (68) 175 (79) 21 (79.5) 13.2 (0.91)
16 x 18 (4.9x5.5) 155 (68) 175 (79) 25 (94.7) 18.6 (1.28)
16 x 20 (4.9x6.1) 155 (68) 175 (79) 29 (109.8) 25 (1.73)
12 x 12 (3.6x3.6)
6-12
(152-305)
155 (68) 175 (79) 22 (83.3) 14.4 (1.0)
14 x 14 (4.3x4.3) 155 (68) 175 (79) 22 (83.3) 14.4 (1.0)
16 x 16 (4.9x4.9) 155 (68) 175 (79) 26 (98.4) 20.1 (1.39)
16 x 18 (4.9x5.5) 155 (68) 175 (79) 31 (117.4) 28.6 (1.97)
*Baseline flows and pressures for 0.05 density
9.
*Calculate for a . 10 density b ut in no case
go below the baseline flows & p ressures
Ordering Information
Specify:
1. Sprinkler Model
2. Sprinkler Type
3. Temperature Rating
4. Sprinkler Finish
5. Escutcheon Finish
Standard Finishes
Sprinkler F1, F2, FP Escutcheons
Bronze
Chrome Plated
White Polyester Coated
Brass
Bright Chrome Plated
White Painted
Special Application Finishes
Sprinkler F1, F2, Escutcheons
Bright Brass
Black Plated
Black Paint
Off White
Satin Chrome
Bright Brass
Black Plated
Black Paint
Off White
Satin Chrome
Finishes
(1)
(1)
Other finishes and colors are available on special order.
Consult factory for details.
