SW NAME TYPE MIDI
MIDI 2 (HOLD
SHIFT)
REMARKS
LOOP IN SW/LED 40/40 60/60
LOOP OUT SW/LED 41/41 61/61
RELOOP/EXIT SW/LED 42/42 62/62
SAVE SW/LED 43/43 63/63
CALL SW/LED 44/44 64/64
SLIP SW/LED 45/45 65/65
VINYL SW/LED 46/46 66/66
EJECT SW/LED 47/47 67/67
SYNC SW/LED 48/48 68/68
KEY LOCK SW/LED 49/49 69/69
PITCH RESET SW/LED 4A/4A 6A/6A
CUE SW/LED 4B/4B 6B/6B
PLAY SW/LED 4C/4C 6C/6C
BACK SW/LED 4D/4D 6D/6D
INFO/ROOT SW/LED 4E/4E 6E/6E
1/8 SW/LED 4F/4F 6F/6F
1/4 SW/LED 50/50 70/70
1/2 SW/LED 51/51 71/71
1/1 SW/LED 52/52 72/72
2/1 SW/LED 53/53 73/73
4/1 SW/LED 54/54 74/ 74
8/1 SW/LED 55/55 75/75
|<< SW 56 76
>>| SW 57 77
PITCH BEND - SW 58 78
PITCH BEND + SW 59 79
Enter/SELECT SW/ENC 5A/03 7A/04
Touch/JOG SW/ENC 5B/01 7B/02
TAP SW 5C --
TIME SW 5D --
PITCH RANGE SW 5E --
UTILITY SW 5F --
Pitch Silder VR PITCHBEND 05
<< SEARCH >> VR 06 07
100 LED 56 76
16 LED 57 77
8 LED 58 78
4 LED 59 79
PITCH 0(R) LED 5A 7A
PITCH 0(G) LED 5B 7B
CC-ABSOLUTE (VR)
Control Change messages are sent with status 0xBn, where n is the channel, for the specied CC controller. Thus the controller MIDI ID
is indicated with the channel along with the CC number. The value from 0x00 to 0x7F, directly related to the location of the controller.
CC-RELATIVE (ENC)
Control Change messages are status 0xBn, where n is the channel, for the specied CC controller. Thus the controller MIDI ID is in
-
dicated with the channel along with the CC number. The value from 0x40 to indicate the change in the controller. This is an offset to
0x40 “one’s complement” notation.
A message with data 0x43 indicates a positive change of 3.
A messages with data 0x31 indicates a negative change of 15.
SWITCH ON/OFF (SW,CENTER,CW,CCW)
These messages are used for switches.
Control Change messages are sent with status 0x9n, SWITCH On and Off value are 0x7F and 0x00, where n is the channel.
LED ON/OFF (LED)
These messages are used for LED.
Control Change messages are sent with status 0x9n, LED On and Off value are 0x7F and 0x00, where n is the channel.
