P 320 20/09/2011 - 300016245-001-D
Mounting P 320

Warning: Assemble the boiler in the order given by the
numbers of each figure, in compliance with all the
instructions.

Refer to the applicable price list for any optional features used.
Package list: Before starting to assemble the boiler, refer to the table
below to check if you have received all the packages required.
1. Boiler body + Accessories
- Boilers supplied with an assembled body
- For boiler supplied with the boiler body in bulk
2. Burner door
3. Baffle plates
4. Casing
5. RC 6 control panel
6. Technical documents
Number of sections 4 5 6 7 8 9
Assembled boiler body
(contents depend upon model)
111111
Accessories package FD 15 FD 15 FD 19 FD 19 FD 19 FD 20
Number of sections 4 5 6 7 8 9
Front section Package 8219-0002 111111
Intermediate section Package 8219-0001 234561
Rear section Package 8219-8960 111111
Set of assembly rods 111111
Accessories for body in bulk 1 Package FD 9 FD 10 FD 11 FD 12 FD 13 FD 14
Base frame 1 Package FD 30 FD 31 FD 32 FD 33 FD 34 FD 35
Number of sections 4 5 6 7 8 9
Burner door 1 Package BP 13 BP 13 BP 13 BP 13 BP 13 BP 13
Number of sections 4 5 6 7 8 9
Baffle plates 1 Package BP 16 BP 17 BP 17 BP 19 BP 20 BP 21
Number of sections 4 5 6 7 8 9
Casing 1 Package MD7 MD8 MD9 MD10 MD11 MD12
Front panel 1 Package RA41 RA41 RA41 RA41 RA41 RA41
Number of sections 4 5 6 7 8 9
1 Package
(Content depends upon country)
111111
