11
List of spare parts PGT 60
Fig.-No. Description EDV-Nr.
1 transport handle 1101142
2 outside casing 1101420
3 insulation 1101421
4 combustion chamber 1101422
5 gasburner 1101423
6 blow out protection grille 1101424
7 gas nozzle 1101426
8 gas pipe R/D 1101457
9 angled coupling 1/8" x 6mm 1101316
10 ignition electrode 1101280
11 ionisation electrode 1101186
12 ionisation cable 1101187
13 connecting clip 1101181
14 ignition cable 1101521
15 support bracket, front 1101427
16 base 1101428
17 inspection cover 1101469
18 support bracket, rear 1101249
19 gas pipe M/R 1101441
20 GE–coupling 1/4" x 6mm 1101396
21 tube fitting M10x1 1101409
22 terminal strip, 4er 1101442
23 gas regulator 1101412
24 burner relay socket 1102534
25 automatic burner relay 1101526
26 push-botton extension 1101524
27 cover plate 1101525
28 socket 1101528
29 safety thermostat with sensitive element 1101197
30 solenoid valve 1101376
31 thermostat socket 1101018
32 shunt plug 1101019
33 gas connection nipple 3/8" lks. 1101134
34 control knob, cpl. 1101192
36 traction relief 1101267
37 operating switch 1101188
38 ignition transformer 1101520
39 protection socket 1101304
40 connecting cable with plug 1101320
41 air suction grille 1101432
42 fan motor 1101254
43 clutch plate B 8 ø 1101255
44 fan blade 1101150
45 retaining bracket 1101395
46 clutch disc 1101375
not shown: pressure controller with hose-break protection
1101470
2 running metres gas hose 1101419
2 running metres HD gas hose (for building sites) 1101174
5 running metres HD gas hose (for building sites) 1108410
10 running metres HD gas hose (for building sites) 1108411
multi-cylinder set (2 - 3 cylinders) 1014050
T - connection for multi-cylinder set 1101177
nylon seal for T - connection 1101178
HD - gas hose 0,4m for multi-cylinder set 1101179
thermostat plug 1101020
When ordering spare parts it is necessary to indicate
EDV- No. and machine no.(see data plate)!
