9
List of spare parts PGT 30
Fig.-No. Description
1 transport handle
2 outside casing
3 combustion chamber
4 end plate, front
5 blow out protection grille
6 safety thermostat with sensitive element
7 inspection cover
8 ignition cable
9 ignition transformer
10 burner relay socket
11 automatic burner relay
12 ionisation cable
13 terminal strip, 4er
14 ionisation electrode
15 ignition electrode
16 connecting clip
17 angled coupling 1/8"x6mm
18 gas nozzle
19 gas pipe M/R
20 gas regulator
21 gas pipe R/D
22 tube fitting M10x1
23 GE–coupling 1/4"x 6mm
24 solenoid valve
25 gas connection nipple 3/8" links
27 control knob, cpl.
28 shunt plug
29 thermostat socket
30 operating switch
31 traction relief
32 connecting cable with plug
33 end plate, rear
34 fan motor
35 clutch plate B 6 Ø
35 clutch plate B 7 Ø
36 fan blade
37 clutch disc
38 gas burner
39 protection socket
40 retaining bracket
not shown: pressure controller with hose-break protection
2 running metres gas hose
2 running metres HD gas hose (for building sites)
5 running metres HD gas hose (for building sites)
10 running metres HD gas hose (for building sites)
multi-cylinder set (2 - 3 cylinders)
T - connection for multi-cylinder set
nylon seal for T - connection
HD - gas hose 0,4m for multi-cylinder set
thermostat plug
When ordering spare parts it is necessary to indicate
EDV- No. and machine no.(see data plate)!
EDV-Nr.
1101142
1101440
1101384
1101382
1101383
1101197
1101385
1101521
1101520
1102534
1101526
1101187
1101442
1101186
1101180
1101181
1101316
1101159
1101441
1101411
1101453
1101409
1101396
1101376
1101134
1101192
1101019
1101018
1101188
1101267
1101320
1101415
1108049
1108455
1108014
1101392
1101375
1101417
1101304
1101395
1101470
1101419
1101174
1108410
1108411
1014050
1101177
1101178
1101179
1101020
