2 Airplane and Systems Descriptions
Airplane and Systems Descriptions 2 - 8
2.11 Dual Throttle, Oil Temperature Control,
Additional Terminals
Two extension panels are located to the left and to right of the
cockpit frame which are used as follows:
At the upper position the oil
temperature control is installed.
Push – to increase temperature,
Pull – to decrease temperature.
At the lower position the dual
throttle control is located. The dual
throttle lever does not feature a
friction lock.
At the upper position the 12V
receptacle for external use (i.e.
portable GPS) is installed. Beneath
you will find two audio-in
connectors (if fitted).
This panel is also prepared to add
2 Sub-D 9-pin connectors, to be
used as PC interface for
connecting installed devices to a
personal computer.
An USB-Converter is provided with
the basic equipment for the
aircraft.
