REMS Power-Press - Technical Data

●
Do not open the battery or modify its construction.
There is a risk of explosion
and fi re due to short-circuiting.
●
Non utilizzare batterie con alloggiamento difettoso o con contatti danneggiati.
Damage to or improper use of the battery can cause fumes to escape. The fumes
can irritate the respiratory tracts. Let in fresh air and consult a doctor in case of
symptoms.
●
Fluid
can leak from the battery when used improperly. Do not touch the fl uid.
Leaking battery fl uid can cause skin irritation and burns. Rinse off immediately
with water in case of contact. Also consult a doctor if the fl uid gets into the eyes.
●
Observe the sa
fety instructions on the battery and the rapid charger.
●
Keep unused batteries away from paper clips, coins, keys, nails, screws
or other small metal objects which could cause bridging of the contacts.
There is a risk of explosion and fi re due to short-circuiting.
●
Remove the battery before stowing/storing the power tool for long periods
of time.
Protect the battery contacts against short-circuiting, e.g. with a cap. This
reduces the risk of fl uids escaping from the batteries.
●
Do not throw defective batteries in the normal household waste.
Hand the
defective batteries over to an authorised REMS contract service workshop or a
recognised disposal company. Observe the national regulations. See also page
6. Disposal.
●
Keep batteries out of reach of children.
Batteries can be life threatening if
swallowed, seek medical assistance immediately.
●
Avoid contact with leaking batteries.
Leaking fl uid can cause skin irritation
and burns. Rinse off immediately with water in case of contact. Also consult a
doctor if the fl uid gets into the eyes.
●
Take the batteries out of the power tool when they are empty.
This reduces
the risk of fl uids escaping from the batteries.
●
Never recharge the non-rechargeable batteries, open them, throw them on
fi res or create a short-circuit.
The batteries can cause fi res and burst. There
is a risk of injury
.
is a risk of injury.is a risk of injury
Explanation of symbols
WARNING
Danger with a medium degree of risk which could result in
death or severe injury (irreversible) if not heeded.
CAUTION
CAUTION
Danger with a low degree of risk which could result in minor
injury (reversible) if not heeded.
NOTICE
Material damage, no safety note! No danger of injury.
Read the operating manual before starting
Use eye protection
Use ear protection
Electrical device complies with protection class II
Environmental friendly disposal
CE conformity mark
1. Technical Data
Intended use
WARNING
REMS radia
l presses are inten
ded for the purpose of making press joints of all
common pressfi tting systems.
REMS cropping tongs are intended for the purpose of cropping threaded bars up to
the strength class 4.8 (400 N/mm²).
REMS cable shears are intended for the purpose of cropping electric cables
≤ 300 mm² (Ø 30 mm).
REMS axial presses are intended for the purpose of making compression sleeve
connections.
REMS pipe expanders are intended for the purpose of expanding and calibrating
pipes.
REMS batteries are intended for supplying energy to the REMS cordless drive units
and the REMS cordless LED lamp.
Note voltage of the batteries.
Rapid chargers are intended for charging the REMS batteries.
All othe
r uses are
not for the intended purpose and are prohibited.
1.1. Scope of Supply
Electrical radial presses/pipe expanders: Drive unit, instruction manual, sheet
steel case
Cordless presses/pipe expanders: Drive unit, Li-Ion battery, rapid charger,
instruction
manual, sheet steel case
1.2. Article nu
mbers
REMS P
ower-Press SE drive unit 572101
REMS Power-Press drive unit 577001
REMS Power-Press ACC drive unit 577000
REMS Power-Press XL ACC drive unit 579000
REMS Mini-Press ACC drive unit 578001
REMS Mini-Press 22 V ACC drive unit 578002
REMS Mini-Press S 22 V ACC drive unit 578003
REMS Akku-Press drive unit 571003
REMS Akku-Press ACC drive unit 571004
REMS Ax-Press 25
22 V
ACC drive unit 573020
REMS Ax-Press 25 L 22 V ACC drive unit 573021
REMS Ax-Press 30 22 V drive unit 573008
REMS Akku-Ex-Press 22 V ACC drive unit 575010
REMS Power-Ex-Press Q & E ACC drive unit 575007
Expander device Cu (REMS Akku-Ex-Press 22 V ACC) 575252
Expander device P (REMS Akku-Ex-Press 22 V ACC) 575253
Expander device Q & E (REMS Akku-Ex-Press 22 V ACC) 575256
Expanding device
16
– 40 mm, ½ – 1½"
(REMS Power-Ex-Press Q & E ACC) 575100
Expanding device
50
– 63 mm, 2"
(REMS Power-Ex-Press Q & E ACC) 575101
REMS battery Li-Ion 14.4 V, 1.5 Ah 571545
REMS battery Li-Ion 14.4 V, 3.0 Ah 571555
REMS battery Li-Ion 21.6 V, 1.5 Ah 571570
REMS battery Li-Ion 21.6 V, 2.5 Ah 571571
Rapid charger Li-Ion/Ni-Cd 230 V 571560
Rapid charger Li-Ion 230 V 571575
Voltage supply 230 V, instead of 14.4 V batteries 571565
Voltage supply 230 V, instead of 21.6 V batteries 571567
Sheet steel case, REMS Power-Press SE 570280
Sheet steel case, REMS Power-Press 570280
Sheet steel case, REMS Power-Press ACC 570280
Transport box XL REMS Power-Press XL ACC 579240
Sheet steel case, REMS Mini-Press ACC / Mini-Press 22 V ACC /
REMS Mini-Press S 22 V ACC 578290
System case L-Boxx REMS Mini-Press ACC /
REMS Mini-Press 22 V ACC / REMS Mini-Press S 22 V ACC 578299
Sheet steel case, REMS Akku-Press / REMS Akku-Press ACC 571290
Sheet steel case, REMS Ax-Press 25 22 V ACC /
Ax-Press 25 L 22 V ACC 578290
Sheet steel case, REMS Ax-Press 30 22 V 573282
Sheet steel case, REMS Akku-Ex-Press 22 V ACC 578290
Sheet steel case, REMS Power-Ex-Press Q & E ACC 575278
REMS CleanM 140119
1.3. Capacity
REMS Mini-Press ACC / Mini-Press 22 V ACC /
REMS Mini-Press S 22 V ACC Radial press
for making press joints in all standard press fi tting systems
on steel pipes, stainless steel pipes, copper pipes, plastic
pipes, composite pipes Ø 10 – 40 mm
Ø
⅜
– 1¼"
REMS Power-Press SE / REMS Power-Press / Power-Press ACC /
Power-Press XL ACC / REMS Akku-Press / Akku-Press ACC
for making press joints of all common pressfi tting systems on steel pipes,
stainless steel pipes, copper pipes, plastic pipes,
composite pipes Ø 10 – 108
(110)
mm
Ø ⅜ – 4
"
REMS Ax-Press 25 22 V ACC / 25 L 22 V ACC for making
compression sleeve joints (sliding sleeve joints)
on plastic pipes, composite pipes Ø 12 – 40 mm
REMS Ax-Press 30 22 V for making compression sleeve
joints (sliding sleeve joints) with pinch sleeve on plastic pipes,
composite pipes Ø 12 – 32 mm
REMS Akku-Ex-Press 22 V ACC with expander Cu
for expanding and calibrating soft copper pipes
s ≤ 1.5 mm
,
soft aluminium pipes
s ≤ 1.2 mm
, soft precision steel pipes
s ≤ 1.2 mm
, soft stainless steel pipes
s ≤ 1 mm
Ø 8 – 42 mm
Ø ⅜ – 1¾
"
REMS Akku-Ex-Press 22 V ACC with expander P
for expanding plastic pipes, composite pipes Ø 12 – 40 mm
REMS Akku-Ex-Press 22 V ACC with expander Q & E
for expanding pipes/rings for the Uponor system
Quick & Easy
and Giacomini GX System
Ø 16 – 40 mm
Ø ½ – 1½
"
s ≤ 4.95 mm
REMS Power-Ex-Press Q & E ACC for expanding
pipes/rings for the Uponor system Quick & Easy
and Giacomini GX System
Ø 16 – 63 mm
Ø ½ – 2
"
s ≤ 6.3 mm
Operating tem
perature range
REMS cordless presses –10 °C – +60 °C (14 °F – +140 °F)
Battery –10 °C – +60 °C (14 °F – +140 °F)
Rapid charger 0 °C – +40 °C (32 °F – +113 °F)
Mains operated presses –10 °C – +60 °C (14 °F – +140 °F)
Storage temperature range > 0°C (32 °F)
1.4. Thrust
Thrust of radial presses, without Mini radial press 32 kN
Thrust REMS Mini-Press ACC / Mini Press 22 V ACC
/
REMS Mini-Press S 22 V ACC 22 kN
