1.70
ENG_UD72178_2
Afficheurs et indicateurs (LJL - Renault)
DISPLAYS AND INDICATORS (3/7)
Fuel gauge 15
If the level is at the minimum, warn-
ing light
M integrated in the indica-
tor comes on orange, accompanied by
a beep. Fill up as soon as possible.
15
Coolant temperature indicator 14
In normal use, indicator 14 should be
before area 13. Under “intensive” op-
erating conditions, the needle may ap-
proach this zone. This is not serious
unless the warning light
® comes
on accompanied by a message on the
instrument panel and a beep.
14
13
