3.3
ENG_UD54787_1
Aérateurs (sorties air) (HFE - Renault)
Side air vents
Air flow
Move the control knob 11 (beyond the
resistance point).
Upwards: closed.
Down: maximum air flow.
Direction
Move the cursors 12 to the desired po-
sition.
Centre air vents.
Air flow
Move the control knob 10 (beyond the
resistance point).
Upwards: closed.
Down: maximum air flow.
Direction
Move the cursors 9 to the desired po-
sition.
AIR VENTS, air outlets (2/2)
11
12
Do not add anything to the
vehicle’s ventilation circuit
(for example, to remove
bad odours).
There is a risk of damage or of
fire.
10
9
