Fusibles (HFE - Renault)
FUSES (3/3)
Allocation of fuses
(the presence of certain fuses depends on the vehicle equipment level)
Symbol Allocation Symbol Allocation
D
Indicators
Steering column controls
ß
Brake light
ñ
Heated seats
Audio amplifier
C
Heated rear screen
N
Door locking/unlocking
Electric door mirror
f
Wipers
ë
Accessories sockets
Z
Interior lighting, courtesy mirror, rain and
light sensor, electric rear view mirrors, air
conditioning, ECO mode
Passenger compartment central unit, speed
limiter/cruise control, diagnostics socket, electric
windows, 4-wheel drive transmission (4WD)
î
Radio, multifunction screen, multimedia sockets
