3.41
ENG_UD59508_2
Filet de séparation (HFE - Renault)
LUGGAGE NET (2/2)
6
– fix the net belt hook 9 onto the an-
choring points 10;
– adjust net strap 8 so that it is taut.
The seatbacks must not touch the
luggage net.
Fitting the luggage net
behind the rear seats
Inside the vehicle on each side:
– slide the cover 6 to access the lug-
gage net upper mounting rail;
– insert upper rod 7 for the net into the
rail;
7
6
8
10
9
