1.46
ENG_UD73493_3
sieges enfant : installation par ceinture de securité (HFE - Renault)
CHILD SEATS: attachment by seat belt (2/3)
Type of child seat Weight of the child
Front passenger
seat
Rear side seats Rear centre seat
Carrycot fitted
across the vehicle
Group 0
< 10 kg X U (3) X
Rear-facing shell
seat
Groups 0 or 0 +
< 10 kg and < 13 kg U (1) (2) U (4) X
Shell seat/rear-facing
seat
Groups 0+ and 1
< 13 kg and 9 to 18 kg U (1) (2) U (4) X
Forward-facing seat
Group 1
9 to 18 kg X U (5) X
Booster seat
Groups 2 and 3
15 to 25 kg and 22 to
36 kg
X U (5) X
(1) RISK OF DEATH OR SERIOUS INJURY: Before installing a child seat on the front passenger seat, check that
the airbag has been deactivated (please refer to “Child safety: front passenger airbag deactivation and activation” in
Section 1).
The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-
ble regulations are respected.
