air bag........................................................
(current page)
airbags
activation/deactivation of the front pas-
senger airbag .......................................
(current page)
seat belts ...................................................
(up to the end of the DU)
child restraint/seat .....................................
(up to the end of the DU)
children ......................................................
(up to the end of the DU)
Isofix ..........................................................
(up to the end of the DU)
child restraint/seat .....................................
(up to the end of the DU)
child safety.................................................
(up to the end of the DU)
child seats..................................................
(up to the end of the DU)
child restraint/seat .....................................
(up to the end of the DU)
transporting children ..................................
(up to the end of the DU)
1.48
ENG_UD72690_3
sieges enfant : fixation par système isofix (HFE - Renault)
CHILD SEATS: attachment using the ISOFIX SYSTEM (1/3)
The table below summarises the information already shown in the diagram on the following pages, to ensure the appli-
cable regulations are respected.
Type of child seat
Weight of
the child
Seat size
ISOFIX
Front passenger seat
Rear side
seats
(depending on
the vehicle)
Rear centre
seat
(depending
on the
vehicle)
Without airbag
or with airbag
deactivated
With airbag
activated
Carrycot fitted
across the vehicle
Group 0
< 10 kg
F, G
[L1, L2]
X X X X
Rear-facing shell
seat
Groups 0 or 0 +
< 10 kg and
< 13 kg
E
[R1]
X X IL (1) X
Shell seat/rear-facing
seat
Groups 0+ and 1
< 13 kg and 9 to
18 kg
C [R3],D [R2] X X IL (1) X
Forward-facing seat
Group 1
9 to 18 kg
A, B, B1 [F3,
F2, F2X]
X X IUF - IL (2) X
Booster seat
Groups 2 and 3
15 to 25 kg and
22 to 36 kg
[B2] X X IUF - IL (2) X
i-Size seat X X X X X X
