control instruments ....................................
(up to the end of the DU)
indicators:
instrument panel ..................................
(up to the end of the DU)
instrument panel ........................................
(up to the end of the DU)
warning lights.............................................
(up to the end of the DU)
fuel level ....................................................
(current page)
display .......................................................
(up to the end of the DU)
1.64
ENG_UD54742_1
Tableau de bord : afficheurs et indicateurs (HFE - Renault)
DISPLAYS AND INDICATORS (1/2)
Instrument panel A
You can customise your instrument
panel with the content and colours of
your choice.
For vehicles fitted with a navigation
system, refer to the handbook for the
equipment.
For vehicles not fitted with a naviga-
tion system, refer to the information on
“Vehicle settings customisation menu”
in Section 1.
Rev counter 4
(graduations x 1000)
A
5
3
Driving style indicator 3
Please refer to the information on “Eco-
driving” in Section 2.
Speedometer 5
(km or miles per hour)
This is displayed differently according
to how the instrument panel is custom-
ised.
Overspeed buzzer
Depending on the vehicle and coun-
try, a buzzer sounds for approximately
10 seconds every 40 seconds, as long
as the vehicle is travelling in excess of
72 mph (120 km/h).
6
Instrument panel in miles
(option to switch to km/h)
Vehicles not fitted with a navigation
system
– With the ignition off, press the OK
button 2 and the start button 6;
– using control 1, select “Settings”,
“Instrument panel”, then the unit;
– Press the OK button 2 to confirm.
To return to the previous mode, repeat
the same operation.
4
1
2
