Renault KOLEOS - Centre Air Vents; Side Air Vents

3.3
Side air vents
Air flow
Move the control knob 14 or 15 (beyond
the resistance point).
14 left or 15 right: closed.
14 right or 15 left: maximum air flow.
Direction
Move the cursors 13 to the desired po-
sition.
Centre air vents.
Air flow
Move the control knob 11 or 12 (beyond
the resistance point).
11 left or 12 right: closed.
11 right or 12 left: maximum air flow.
Direction
Move the cursors 10 to the desired po-
sition.
AIR VENTS, air outlets (2/2)
14
13
Do not add anything to the
vehicle’s ventilation circuit
(for example, to remove
bad odours).
There is a risk of damage or of
fire.
10
12 11
15
13
