1.42
CHILD SEATS: attachment by seat belt (2/3)
Type of child seat Weight of the child
Front passenger
seat (1) (2)
Rear side seats
Rear centre
seat
Without airbag
or with airbag
deactivated
With airbag
activated
Carrycot fitted
across the vehicle
Group 0
< 10 kg X X U (3) X
Rear-facing shell
seat
Groups 0 or 0 +
< 10 kg and < 13 kg U X U (4) U (6)
Shell seat/rear-facing
seat
Groups 0+ and 1
< 13 kg and 9 to 18 kg U X U (4) U (6)
Forward-facing seat
Group 1
9 to 18 kg U X U (4) (5) U (6)
Booster seat
Groups 2 and 3
15 to 25 kg and 22 to
36 kg
U U U (4) (5) U
(1) RISK OF DEATH OR SERIOUS INJURY: Before installing a child seat on the front passenger seat, check that
the airbag has been deactivated (please refer to “Child safety: front passenger airbag deactivation and activation” in
Section 1).
The table below summarises the information already shown on the diagram on the previous page, to ensure the applica-
ble regulations are respected.
